Name: Cisco 3850 Power Supply 715W AC Config 1 Power Supply PWRC1715WAC
Brand: Cisco
Price: 118.00 USD

Brand Name : Cisco

Place of Origin : BEIJING

MOQ : 2 pieces

Price : $118.00/pieces 2-299 pieces

Model Number : PWR-C1-715WAC

Payment Terms : T/T, Western Union

Supply Ability : 80 Piece/Pieces per Day

Delivery Time : 2-5 work days

Packaging Details : Brand new original unopened, Carton box

Private Mold : NO

Products Status : Stock

Product name : Power

Condition : NIB Original

Warranty : 1 Year

Type : Power Module

Model : PWR-C1-715WAC

Lead Time : 2~5 Days

SHIPPING : DHL FEDEX UPS ARAMEX

Contact Now

Product Description

Cisco 3850 Series 715W AC Config 1 Power Supply PWR-C1-715WAC

PWR-C1-715WAC= Specification
Power supply rated maximum	715W
Total output BTU (Note: 1000 BTU/hr = 293W)	2465 BTU/hr, 715W
Input-voltage range and frequency	100-240VAC, 50-60 Hz
Input current	10-5A
Output ratings	-56V at 12.8A
Output holdup time	16.7 ms minimum at 100VAC
Power-supply input receptacles	IEC 320-C16 (IEC60320-C16)
Power cord rating	13A
Physical specifications	(H x W x D): 1.58 X 3.25 X 12.20 in
Operating temperature	23 to 113°F (-5 to 45°C)
Storage temperature	-40 to 158°F (-40 to 70°C)
Relative humidity operating and nonoperating noncondensing	5 to 90% noncondensing
Altitude	10,000 ft. (3000 meters), up to 45°C
MTBF	Calculated MTBF must be greater than 300,000 using Telcordia SR-332, Method 1, Case 3. Demonstrated MTBF is 500,000 hr (with 90% confidence level).
EMI and EMC compliance	FCC Part 15 (CFR 47) Class A ICES-003 Class A EN 55022 Class A CISPR 22 Class A AS/NZS 3548 Class A BSMI Class A (AC input models only) VCCI Class A EN 55024, EN300386, EN 50082-1, EN 61000-3-2, EN 61000-3-3 EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN 61000-6-1
Safety compliance	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking
LED indicators	“AC OK”: Input power to the power supply is OK “PS OK”: Output power from the power supply is OK
